"CPU SIEMENS S7 "312 series
SIMATIC S7-300 CPU 312 (پی ال سی زیمنس) Entry CPU for small-scale applications with moderate requirements on the processing speed. MPI-interface onboard, Comprehensive integrated system diagnosis,Supports ideally the insert of SIMATIC Engineering Tools
مشخصات
- CPU 312 :
- 6ES7 312-1AD10-0AB0
- CPU 312 :
- 6ES7 312-1AE13-0AB0
- CPU 312 :
- 6ES7 312-1AE14-0AB0
- CPU 312 IFM :
- 6ES7 312-5AC00-0AB0
- CPU 312 IFM :
- 6ES7 312-5AC01-0AB0
- CPU 312 IFM :
- 6ES7 312-5AC02-0AB0
- CPU 312 IFM :
- 6ES7 312-5AC81-0AB0
- CPU 312 IFM :
- 6ES7 312-5AC82-0AB0
- CPU 312C :
- 6ES7 312-5BD00-0AB0
- CPU 312C :
- 6ES7 312-5BD01-0AB0
- CPU 312C :
- 6ES7 312-5BE03-0AB0
- CPU 312C :
- 6ES7 312-5BF04-0AB0
توضیحات محصول
CPU S7 312 SERIES
|
Part no |
TYPE |
Specification |
|
6ES7 312-1AD10-0AB0 |
CPU 312 |
Work memory 16 KB; 0.2 ms/1000 instructions; MPI connection; single-tier configuration up to 8 modules; S7 communication (loadable FBs/FCs); Firmware V2.0 |
|
6ES7 312-1AE13-0AB0 |
CPU 312 |
Work memory 32 KB; 0.2 ms/1000 instructions; MPI connection; single-tier configuration up to 8 modules; S7 communication (loadable FBs/FCs); firmware V2.6 |
|
6ES7 312-1AE14-0AB0 |
CPU 312 |
Work memory 32 KB; 0.1 ms/1000 instructions; MPI connection; single-tier configuration up to 8 modules; S7 communication (loadable FBs/FCs); firmware V3.3 |
|
6ES7 312-5AC00-0AB0 |
CPU 312 IFM |
Work memory 6 KB; 0.6 ms/1000 instructions; DI10/DO6 integrated; MPI connection; single-tier configuration up to 8 modules |
|
6ES7 312-5AC01-0AB0 |
CPU 312 IFM |
Work memory 6 KB; 0.6 ms/1000 instructions; DI10/DO6 integrated; MPI connection; single-tier configuration up to 8 modules |
|
6ES7 312-5AC02-0AB0 |
CPU 312 IFM |
Work memory 6 KB; 0.6 ms/1000 instructions; DI 10/DO 6 integrated; MPI connection; single-tier configuration up to 8 modules; S7 Communication (loadable FBs/FCs); firmware V1.2 |
|
6ES7 312-5AC81-0AB0 |
CPU 312 IFM |
Work memory 6 KB; 0.6 ms/1000 instructions; DI10/DO6 integrated; MPI connection; single-tier configuration up to 8 modules; extended environmental conditions |
|
6ES7 312-5AC82-0AB0 |
CPU 312 IFM |
Work memory 6 KB; 0.6 ms/1000 instructions; DI 10/DO 6 integrated; MPI connection; single-tier configuration up to 8 modules; S7 Communication (loadable FBs/FCs); expanded environmental conditions; firmware V1.2 |
|
6ES7 312-5BD00-0AB0 |
CPU 312C |
Work memory 16 KB; 0.2ms/1000 instructions; DI10/DO6 integrated; 2 pulse outputs (2.5 kHz); 2 channels counting and measuring incremental encoders 24 V (10 kHz); MPI connector; single-tier configuration up to 8 modules; firmware V1.0 |
|
6ES7 312-5BD01-0AB0 |
CPU 312C |
Work memory 16 KB; 0.2ms/1000 instructions; DI10/DO6 integrated; 2 pulse outputs (2.5kHz); 2 channel counting and measuring with incremental encoders 24V (10kHz); MPI connector; single-tier configuration up to 8 modules; Firmware V2.0; also available as SIPLUS module with order number 6AG1 312-5BD01-2AB0 |
|
6ES7 312-5BE03-0AB0 |
CPU 312C |
Work memory 32KB; 0.2ms/1000 instructions; DI10/DO6 integrated; 2 pulse outputs (2.5kHz); 2 channel counting and measuring with incremental encoders 24V (10kHz); MPI connector; single-tier configuration up to 8 modules; firmware V2.6 |
|
6ES7 312-5BF04-0AB0 |
CPU 312C |
Work memory 64KB; 0.1ms/1000 instructions; DI10/DO6 integrated; 2 pulse outputs (2.5kHz); 2 channel counting and measuring with incremental encoders 24V (10kHz); MPI connector; single-tier configuration up to 8 modules; firmware V3.3 |
