توربیدی متر (کدورت سنج) رومیزی مدل HI88713-02 هانا آمریکا
شرکت نوآوران تجهیز تامین کننده ی تمامی محصولات کمپانی هانا از جمله انواع کدورت سنج های این کمپانی می باشد
توضیحات محصول
- Specifications
- Accessories
- Downloads
| Range | FNU Mode | 0.00 to 9.99; 10.0 to 99.9; 100 to 1000 FNU |
| FAU Mode | 10.0 to 99.9; 100 to 4000 FAU | |
| NTU Ratio Mode | 0.00 to 9.99; 10.0 to 99.9; 100 to 4000 NTU 0.00 to 9.99; 10.0 to 99.9; 100 to 980 EBC | |
| NTU Non-Ratio Mode | 0.00 to 9.99; 10.0 to 99.9; 100 to 1000 NTU 0.00 to 9.99; 10.0 to 99.9; 100 to 245 EBC | |
| Resolution | FNU Mode | 0.01; 0.1; 1 FNU |
| FAU Mode | 0.1; 1 FAU | |
| NTU Ratio Mode | 0.01; 0.1; 1 NTU / 0.01; 0.1; 1 EBC | |
| NTU Non-Ratio Mode | 0.01; 0.1; 1 NTU / 0.01; 0.1; 1 EBC | |
| Accuracy @25°C | FNU Mode | ±2% of reading plus stray light |
| FAU Mode | ±10% of reading | |
| NTU Ratio Mode | ±2% of reading plus stray light / ±5% of reading above 1000 NTU | |
| NTU Non-Ratio Mode | ±2% of reading plus stray light | |
| Range Selection | automatic | |
| Repeatability | ±1% of reading or stray light, whichever is greater | |
| Stray Light | < 0.1 NTU (0.05 EBC) | |
| Light Detector | silicon photocell | |
| Light Source | IR LED | |
| Method | ISO 7027 Method | |
| Measuring Mode | normal, average, continuous. | |
| Turbidity Standards | <0.1, 15, 100, 750 FNU and 2000 NTU | |
| Calibration | two, three, four or five-point calibration | |
| Log Memory | 200 records | |
| PC Connectivity | USB | |
| Environment | 0°C (32°F) to 50°C (122°F); max 95% RH non-condensing | |
| Power Supply | 12 Vdc power input | |
| Dimensions / Weight | 230 x 200 x 145 mm (9 x 7.9 x 5.7”) / 2.5 Kg (88 oz.) |
