دوربین مدار بسته سقفی تحت شبکه( 1.3MP (IP مدل ITE-1030 , CNB
دوربین مدار بسته سقفی تحت شبکه( 1.3MP (IP مدل ITE-1030 , CNB -1/3Progressive CMOS Sensor -1.3Mega - Pixel Resolution - Lens f=2.97 mm – IP 67- Vandal
توضیحات محصول
دوربین مدار بسته سقفی تحت شبکه( 1.3MP (IP مدل ITE-1030 , CNB
| Model | ITE1030 |
| ..[Camera] | |
Signal System | Progressive image processing |
Scaning System | 16:9 Progressive |
Image Sensor | 1/3" Progerssive CMOS Sensor |
Sync. System | Internal |
Effective Pixels Number | 1280(H) x 1024(V) 1.3 Mega |
Horizontal Resolution | 800 TV Lines |
Video Output Level | Select NTSC/PAL 1.0Vp-p (BNC 75Ω, composite) |
Lens | Built-in Fixed Lens (f=2.97mm, F2.0) |
Min. Illumination | 0.1Lux |
DSS | On/Off(x4) |
Back Light Compensation | On/Off |
Flickerless | On/Off |
White Balance | Auto/Manual |
Digital Noise Reduction | On/Off, 3D-DNR(20 Step), 2D-DNR |
Exposure | Auto |
Function | Color, B/W |
Privacy Zone | Select 10 Zone – each area |
Elec. Shutter Speed | NTSC : 1/30~1/30,000 (21 Step) | PAL : 1/25~1/30,000 (21 Step) |
| ..[Video / Audio] | |
Compression | H.264 / MJPEG |
Frame Rate | Dual Mode : H.246 (30fps) / MJPEG(30fps) * Support 720P Mode |
Resolution | SXGA(1280 x 1024), 720P(1280x720), XD1(720 x 480 / 720 x 576), VGA(640x480), CIF(352 x 240 / 352 x 288) |
| ..[Network] | |
Protocol | IPv4, HTTP, TCP, RTSP, RTP, RTCP, UDP, SMTP, FTP, ICMP, DHCP, UPnP, Bonjour, ARP, DNS, DynDNS, NTP, Multhcast HTTPS, QoS, SNMP *) Onvif, IPv6 |
Supported DDNS | 1.CNB DDNS 2.DynDNS.org 3.Reference code with SDK |
LAN Interface | Ehternet 10/100 Base-T (RJ-45 Type) |
Suppot PoE | Standard IEEE 802.3af supported, End-Span type |
| ..[Security] | |
Access Level Setup | Multiple user access levels with password protection |
Network Security | IP Filtering |
| ..[Alarm and Event Managerment] | |
Image Detection | Motion detection (Select 3 Regions - each area) |
Local Storage | SD/SDHC Card Memory : Max. 16GByte (Class 4 or Higher) |
After Event Process | JPEG Image upload over FTP server / JPEG Image or Notification Message Upload over SMTP (E-mail server) |
Pre/Post alarm | Detail time-set : Max. Pre alarm 5sec. / Post alarm 8sec., Storage (SD card : JPEG Image, H.264 Movie file) |
| ..[Applications] | |
Browser | Internet Explorer 6.0 or higher |
Monitoring Application | XNVR, CNB CMS and Utility (IP-Installer, etc) |
| ..[Maintenance] | |
System Upgrade | Firmware upgrade over HTTP |
| ..[Mechanical] | |
Operating Temperature | -20℃ ~ 50℃ |
Power | 12VDC |
Dimensions/Weight(Net) | 129.8(W) x 52.8(H) x 118.8(D) mm |
Approvals | EN50155 Class T3 (Vibration, Shock, Bump, Temperature) |
