دوربین مدار بسته دید در شب تحت شبکه (ip) مدل WBL-21S
دوربین مدار بسته دید در شب تحت شبکه (ip) مدل WBL-21S - Ultra High Resolution : 600 TV Lines ) - Intelligent IR Technology
توضیحات محصول
دوربین مدار بسته دید در شب تحت شبکه (ip) مدل WBL-21S
| Model | WBL-20S | WBL-21S |
Signal System | NTSC | PAL |
Scanning System | 2:1 Interlace | |
Scanning Frequency(H) | 15.734 KHz | 15.625kHz |
Scanning Frequency(V) | 59.94 Hz | 50Hz |
Image Sensor | 1/3 inch IT CCD | |
Sync. System | Internal | |
Total Pixels Number | 811(H) x 508(V) 410K | 795(H) x 596(V) 470K |
Effective Pixels Number | 768(H) x 494(V) 380K | 752(H) x 582(V) 440K |
Horizontal Resolution | 600 TV Lines (BW 650TV Lines) | |
Video Output Level | 1.0 Vp-p (75Ω, Composite) | |
S/N Ratio | More than 50dB (AGC Off) | |
Lens | Fixed Lens (f=3.8mm or 6mm) | |
Min. Illumination | 0.05 Lux (Color), 0.00 Lux (IR LED On) | |
White Balance | Auto | |
AGC | On/Off | |
IR LED & Sensor | Intelligent IR Technology, IR LEDs 12EA (850nm, 30˚) | Smart IR Technology, IR LEDs 12EA (850nm, 30˚) |
IR LED Lighting Distance | Max. 15m | |
Electronic Shutter Speed | 1/60~1/120,000 Sec. | 1/50~1/120,000 Sec. |
Power Voltage | 12VDC | |
Power Consumption | Max. 6W/0.5A | |
Dimensions | 62.0 x 123.0mm | |
Weight (Net) | Approx. 600g |
