دوربین مدار بسته آنالوگ 540TVL,WDRصنعتی high resolation Hikvision مدل DS-2CC1172 P

1/3" SONY Super HAD CCD 2      Image Sensor

Signal System

PAL/NTSC

Effective Pixels

752(H)x582(V)

Min. Illumination

0.1 lux@F1.2, AGC on

Shutter Time

1/50s to 1/100,000s

Lens Mount

C/CS Mount

Auto Iris

DC/Video Drive

Day& Night

Electronic

Horizontal Resolution

540TVL

Synchronization

Internal synchronization
(-A series support Internal/Power synchronization)

Video Output

1Vp-p Composite Output (75Ω/BNC)

S/N Ratio

More than 52dB

-10 °C - 60 °C (14 °F - 140 °F)
Humidity 90% or less (non-condensing)

Power Supply

12 V DC ± 10%
(-A series support 24 V AC ± 10%, 12 V DC ± 10%)

Power Consumption

2W max.
(-A series: 3W max.)

Dimension

69 x 56 x 113.3 mm
(2.72” × 2.20” × 4.46”)

Weight

400g (0.88 lbs)
