دوربین مدار بسته LILIN,SPEED DOME تحت شبکه (IP) مدلIPG- 012 ES
دوربین مدار بسته SPEED DOME تحت شبکه (IP) مدلIPG- 012 ES -H.264 1/4"Sony Progressive Scan CMOS - HD 720 – Day &Night - ICR / PoE – SD / SDHC Card
توضیحات محصول
دوربین مدار بسته SPEED DOME تحت شبکه (IP) مدلIPG- 012 ES
Camera | |
| Environment: | indoor |
| Type: | fixed view |
| Sensor: | 1/4" progressive scan CMOS, 1280(H) x 800(V) = 1,024,000 (effective pixel) |
| Lens: | 2.8-12mm varifocal megapixel lens (horizontal viewing angle 88° - 25°) |
| Power: | 12V DC or Power over Ethernet (IEEE802.3af compliant) |
| Processor/memory: | Intel Pentium 4 1.8GHz or above with 1GB or above, Independent Display Card |
| Compatibility: | Windows 2000, Windows XP, Windows Vista, Windows 7, browser: Windows Internet Explorer 5.0 or above |
Video | |
| Resolution: | 720P (1280 x 768) / VGA (640 x 384) / CIF (320 x 192) |
| Compression: | H.264/AVC, Motion JPEG |
| Frame-rate: | H.264: up to 20 fps at 720P, MJPEG: up to 10 fps at 720P |
| Bandwidth control: | bit rate 128Kbps to 5Mbps, streaming, RTSP: RTP/HTTP, RTP/TCP, RTP/UDP |
| Minimum illumination: | colour: 2 lux at F1.2; mono: 0.4 lux at F1.2 |
| Imaging: | white balance: auto / tungsten / indoor / fluorescents1 / fluorescents2 / outdoor1 / outdoor2; back light compensation: auto; electronic shutter: 1/30(25)S ~ 1/20,000S |
Viewing, detection & recording | |
| Access: | via local network, internet, iPhone and Andriod support |
| Simultaneous users: | 8 |
| Zoom: | digital only |
| Alarm detection: | events triggered by built-in motion detection |
| Alarm notifications: | image upload over FTP, e-mail by motion detection and external alarm outputs |
| Recording triggers: | motion detection and on alarm |
| SD card recording: | support SD/SDHC card (card not included) |
Compatible recording platforms (not included) | |
| Software: | Merit Lilin CMX recording software (included),Milestone XProtect |
Connections | |
| Power: | socket for 12V DC |
| Network: | 10/100Mbps Base-T, RJ-45 Ethernet connection, Power over Ethernet (POE) IEEE 802.3af |
| Alarm I/O: | digital 1 input / 1 output (N.O.) |
| Card slot: | supports SD/SDHC cards (card not included) |
Other | |
| Dimensions: | body: 56mm(w) x 54mm(h) x 112mm(d) |
| Weight: | 500g |
| Colour: | grey/black |
| Warranty: | 3 year manufacturer warranty |
| Mounting methods: | wall / ceiling mount |
| Operating temperatures: | -10 to 40°C (14 to 104°F) |
| Power consumption: | 12V DC, 6W / PoE, 7.5W |
| Dynamic DNS: | yes |
| Protocols supported: | IP, TCP, UDP, HTTP, SMTP, ESMTP, NTP, DDNS, FTP, ARP, DHCP, PPPoE, DNS, RTSP, RTCP, Telnet |
| Security: | Base64 HTTP encryption, multiple user access levels with password protection |
| ONVIF compliant: | Yes |
