دوربین مدار بسته سقفی دید در شب lilin,SPEED dome,outdoor تحت شبکه (IP) مدلIPR- 712 S
دوربین مدار بسته سقفی دید در شب lilin,SPEED dome,outdoor تحت شبکه (IP) مدلIPR- 712 S -H.264 1/4"Sony Progressive Scan CMOS - HD Megapixel – 25 Meter -Lux 0.05 - Lens 6mm
توضیحات محصول
دوربین مدار بسته سقفی دید در شب lilin,SPEED dome,outdoor تحت شبکه (IP) مدلIPR- 712 S
Camera | |
| Environment: | outdoor |
| Type: | fixed view with built-in infra red LEDs |
| Sensor: | 1/4" progressive scan CMOS, 1280(H) x 800(V) = 1,024,000 (effective pixel) |
| Lens: | Choice between 4.3mm fixed lens (horizontal viewing angle 49.8°) and 6mm fixed lens (horizontal viewing angle 35.8°), iris F1.8 |
| Power: | 12V DC |
| Processor/memory: | Intel Pentium 4 1.8GHz or above with 1GB or above, Independent Display Card |
| Compatibility: | Windows 2000, Windows XP, Windows Vista, Windows 7, browser: Windows Internet Explorer 5.0 or above |
Video | |
| Resolution: | 720P (1280 x 768) / VGA (640 x 384) / CIF (320 x 192) |
| Compression: | H.264/AVC, Motion JPEG |
| Frame-rate: | H.264: up to 20 fps at 720P, MJPEG: up to 10 fps at 720P |
| Bandwidth control: | bit rate 128Kbps to 5Mbps, streaming, RTSP: RTP/HTTP, RTP/TCP, RTP/UDP |
| Day/night: | switchable day/night filter with intregrated infra red LED illumination (850nm), up to 16 metre range at a 30° spread |
| Minimum illumination: | colour: 3 lux at F1.8; mono: 0.6 lux at F1.8; 0 lux (complete darkness) with infra red illumination on |
| Imaging: | white balance: auto / tungsten / indoor / fluorescents1 / fluorescents2 / outdoor1 / outdoor2; back light compensation: auto; electronic shutter: 1/30(25)S ~ 1/20,000S |
Viewing, detection & recording | |
| Access: | via local network, internet, iPhone and Android support |
| Simultaneous users: | 8 |
| Zoom: | digital only |
| Alarm detection: | events triggered by built-in motion detection |
| Alarm notifications: | image upload over FTP and e-mail by motion detection |
| Recording triggers: | motion detection |
| On-camera recording: | support SD/SDHC card for circular recording (card is not included) |
Compatible recording platforms (not included) | |
| Software: | Merit Lilin CMX recording software (included),Milestone XProtect |
Connections | |
| Power: | socket for 12V DC |
| Network: | 10/100Mbps Base-T, RJ-45 Ethernet connection |
| Card slot: | supports SD / SDHC cards (card not included) |
Other | |
| Dimensions: | body: 82mm(W) x 72.5mm(H) x 154mm(D), bracket : 101mm (L) |
| Weight: | 600g |
| Colour: | silver |
| Warranty: | 3 year manufacturer warranty |
| Mounting methods: | wall mount |
| Operating temperatures: | -10 to 50°C (14 to 122°F) |
| Power consumption: | 12V DC, 10W |
| Dynamic DNS: | yes |
| Protocols supported: | IP, TCP, UDP, HTTP, SMTP, ESMTP, NTP, DDNS, FTP, ARP, DHCP, PPPoE, DNS, RTSP, RTCP, Telnet |
| Security: | Base64 HTTP encryption, multiple user access levels with password protection |
| ONVIF compliant: | Yes |
