تستر کابل شبکه و مولتی متر LA-1011



The tester is a newly designed and very practical tester that can easily read the correct pin configuration of 10 Base -T cable(Category 5), 10 Base-2 cable (coax), RJ45/RJ11 moduler cables, 356A, TIA-568A/568B and Token Ring cable by comparing one transmitting end to the corresponding receiving end. With the remote kit it can test cables installed far away either on wall plate or patch panel. It is easy to verify the cable continuity, open, short and cross-connect. It is affordable, so you can benefit the most.



Features:

1.Test the correct pin configuration of 10 Base-T 10 Base-2 Thin Ethernet cable, RJ45/RJ11 modular cables 356A, TIA-568A/568B and Token Ring cable etc.

2.With remote kit it can remotely test cables up to 300 m away either on the wall plate or patch panel

3.Test the ground wire

4.Measures DC/AC Voltage, DC/AC Current, Resistance, Continuity & diode



Specifications:

Function	Max Range	Basic Accuracy
Voltage DC	600V	±0.5%
Voltage AC	600V	±1.2%
Current DC	200mA	±1.5%
Current AC	200mA	±2.0%
Resistance	20MΩ	±0.8%
Continuity Test	Beep if less than 100Ω
Size(HxWxD)	162mm x 74.5mm x 44mm
Weight	308g



Accessories:

9V battery and Two “AAA” batteries, remote terminator, holster, cables, test leads, gift box with carrying case
