دستگاه NVR مدل RS-3132NVR
مشخصات و ویژگی های دستگاه NVR مدل RS-31xxNVR به همراه قیمت و جزئیات این محصول در نظارت گستر ایمن
مشخصات
- تعداد هارد دیسک :
- 2
- تعداد کانال تصویر :
- 4
- تعداد کانال ورودی صدا :
- 16
- حداکثر ظرفیت هارد دیسک (هر عدد) :
- 64 ترابایت
- خروجی تصویر :
- HDMI، VGA
- مدل :
- RS-3132NVR
- برند Raster Red :
- تعداد کانال 16 کانال
- کیفیت ضبط D1 :
- ورودی صدا 16 صدا
- هارد 2 عدد SATA :
- تصویر ورودی IP
- خروجی HDMI, VGA :
- نوع دستگاه NVR
توضیحات محصول
4/8/16 channel 1U standalone Network Video Recorder- Dual-core CPU presents the powerful preview, recording, playback and network performance
- Up to 4 channel 1080P cameras realtime live view
- H.264/MPEG-4 dual codec decoding
- Up to 16 channel@D1, 8 channel@720P, 4 channel@1080P realtime recording
- All channel simultaneous realtime playback, GRID interface & smart search
- Support Multi-brand network cameras such as: RASTER, Arecont Vision, AXIS, Canon, Dynacolor, Panasonic, SAMSUNG, SANYO, SONY and ONVIF
- Support remote network camera encoding setting & image adjust
- IP Search feature to automatically discover network cameras
- Support 2 SATA HDDs up to 6TB, 2 USB2.0
- Built-in web server, CMS(DSS/PSS) & DMSS
| Model | RS-3104 | RS-3108 | RS-3116 |
| System | |||
| Main Processor | High performance Dual-core embedded microprocessor | ||
| Operating System | Embedded LINUX | ||
| System Resources | Pentaplex function: live, recording, playback, backup & remote access | ||
| Control Mode | Front panel, USB mouse, IR remote control, Keyboard, Network | ||
| Video | |||
| IP Camera Input | ۴ch@D1 / 2ch@720P /1ch@1080P | ۸ch@D1 / 4ch@720P / 2ch@1080P | ۱۶ch@D1 / 8ch@720P / 4ch@1080P |
| IP Camera Supported List | RASTER, Arecont Vision, AXIS, Canon, Dynacolor, Panasonic, SAMSUNG, SANYO, SONY, ONVIF | ||
| Output | ۱ HDMI(video & audio), 1 VGA | ||
| Display | |||
| Display Split | ۱/۴ | ۱/۴/۸/۹ | ۱/۴/۸/۹/۱۶ |
| Resolution | ۱۹۲۰×۱۰۸۰, ۱۲۸۰×۱۰۲۴, ۱۲۸۰×۷۲۰, ۱۰۲۴×۷۶۸ | ||
| Tour Display | Support | ||
| Privacy Masking | ۴ self-defined four-sided zones for privacy masking for each camera | ||
| OSD | Camera title, time, video loss, camera lock, motion detection, recording | ||
| Recording | |||
| Compression | H.264 / MPEG4 | ||
| Recording Resolution | ۱۰۸۰P(1920×۱۰۸۰) / ۷۲۰P(1280×۷۲۰) / D1 (704×۵۷۶/۷۰۴×۴۸۰) | ||
| Max Recording Speed | ۱۰۰/۱۲۰fps@D1, 50/60fps@720P , 25/30fps@1080P | ۲۰۰/۲۴۰fps@D1, 100/120fps@720P , 50/60fps@1080P | ۴۰۰/۴۸۰fps@D1, 200/240fps@720P , 100/120fps@1080P |
| Recording Bit Rate | Up to 8Mbps | Up to 16Mbps | Up to 32Mbps |
| Recording Quality | CBR, VBR(1~6 level, level 6 is the best) | ||
| Recording Mode | Manual, Schedule(Regular(Continuous), MD(Video detection: Motion detection, Camera blank, Video loss), Alarm), Stop | ||
| Recording Priority | Manual >Alarm >MD >Regular | ||
| Recording Interval | ۱~۱۲۰ min (default: 60 min) | ||
| Video Detection & Alarm | |||
| Trigger Events | Recording, PTZ movement, Tour, Alarm, Email, FTP, Buzzer & Screen tips | ||
| Motion Detection | Zones: 396(22×۱۸), Sensitivity: 1~6 (level 6 is highest) | ||
| Video Loss & Camera Blank | Support | ||
| Alarm Input | ۴ channel | ۸ channel | ۱۶ channel |
| Relay Output | ۳ channel | ||
| Playback & Backup | |||
| Playback Channel | ۱/۲/۴/All | ||
| Search Mode | Time/Date, Alarm, MD & Exact search (accurate to second), Smart search | ||
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom | ||
| Backup Mode | Flash drive / USB HDD / USB CD&DVD-RW / Network download | ||
| Network | |||
| Ethernet | RJ-45 port (10/100M/1000M) | ||
| Network Function | HTTP, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support RASTER IP camera, DVR, NVS etc) | ||
| Max Remote Users | ۲۰ Users simultaneously | ||
| Remote Operation | Monitor, PTZ control, Playback, System setting, File download, Log information | ||
| Hard Disk | |||
| Hard Disk | ۲ SATA ports, Up to 6TB | ||
| Space Occupation | Max 3.6GB/H per channel | ||
| HDD Management | HDD Group, HDD hibernation technology, HDD faulty alarm & Raid(Redundancy) | ||
| Auxiliary Interface | |||
| USB Interface | ۲ ports, 1 for mouse control, 1 for backup | ||
| RS232 | RASTER keyboard, PC communication | ||
| RS485 | PTZ control | ||
| Environmental | |||
| Power Supply | DC12V/3.3A | ||
| Power Consumption | ۲۰W(without HDD) | ||
| Working Environment | -۱۰ ~+۵۵°C / 10~90%RH / 86~106kpa | ||
| Dimension | ۱U, 375mm×۲۸۵mm×۴۵mm(W×D×H) | ||
| Weight | ۲.۳KG(without HDD) |
