دستگاه NVR مدل RS-8608HBZ3
مشخصات و ویژگی های دستگاه NVR مدل RS-8608HBZ3 به همراه قیمت و جزئیات این محصول در نظارت گستر ایمن دستگاه NVR مدل RS-8608HBZ3
مشخصات
- تعداد هارد دیسک :
- 2
- تعداد کانال تصویر :
- 8
- تعداد کانال ورودی صدا :
- 4
- خروجی تصویر :
- HDMI، TV، VGA
- مدل :
- RS-8608HBZ3
- برند Raster Blue :
- تعداد کانال 8 کانال
- کیفیت ضبط 960H :
- ورودی صدا 4 صدا
- هارد 2 عدد SATA :
- تصویر ورودی IP
- خروجی HDMI, TV, VGA :
- نوع دستگاه Hybrid
توضیحات محصول
Connectable to the third-party network cameras like ACTI, Arecont, AXIS, Brickcom, Bosch, Canon, PANASONIC, Pelco, SAMSUNG, SANYO, SONY, Vivotek and ZAVIO;- Live view, storage and playback of video at up to 5MP resolution;
- Simultaneous HDMI, VGA and CVBS outputs; HDMI output and VGA
- output at up to 1920×1080P resolution.
- New GUI and supports starting record with one key;
- Redundant recording, holiday recording and capture schedule configuration;
- Instant playback for assigned camera during multi-channel live view mode;
- Support up to 16-ch synchronous playback at WD1 resolution; and reverse playback for multi-camera;
- Smart search for the selected area in the video.
- Customization of tags, searching and playing back by tags;
- Locking and unlocking record files;
- Support HDD quota and group management; different capacity can be assigned to different cameras under quota mode;
- Provide up to 2 SATA interfaces for record;
- 1 self-adaptive network interfaces.
- Support Hikvision DDNS (Dynamic Domain Name System);
- Support Channel-zero encoding to decrease the bandwidth requirement when viewing multiple cameras.
- Network detection function;
- Adopt pioneering dual-OS design to ensure the security of system running.
| Model | RS-8608HBZ3 | |
|
Video/Audio input | Analog video input | ۸-ch |
| BNC (1.0 Vp-p, 75 Ω), PAL / NTSC self-adaptive | ||
| IP video input | Up to 16-ch | |
| Composite video input | Up to 16-ch (Analog video + IP video ) | |
| Audio input | ۴-ch | |
| RCA (2.0 Vp-p, 1 KΩ) | ||
| Incoming bandwidth | ۴۰ Mbps | |
|
Video/Audio output | HDMI / VGA output | ۱۹۲۰ ×۱۰۸۰ / ۶۰ Hz (1080P), 1600 ×۱۲۰۰ / ۶۰ Hz, 1280 ×۱۰۲۴ / ۶۰ Hz, 1280 ×۷۲۰ / ۶۰ Hz,
۱۰۲۴ ×۷۶۸ / ۶۰ Hz |
| CVBS output | ۱-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 ×۵۷۶, NTSC: 704 ×۴۸۰ | |
| Audio output | ۱-ch, RCA (Linear, 1 KΩ) | |
| Max. remote connection | ۱۲۸-ch | |
| Outgoing bandwidth | ۲۴۰ Mbps | |
|
Encoding/Decoding Parameters | Video compression | H.264 |
| Encoding resolution | Main stream: WD1 / 4CIF / 2CIF / CIF / QCIF | |
| Sub-stream: CIF / QCIF | ||
| Frame rate | Main stream: 25 fps (P) / 30 fps (N) | |
| Sub-stream: 25 fps (P) / 30 fps (N) | ||
| Video bitrate | ۳۲ Kbps ~ 3 Mbps | |
| Audio compression | OggVorbis | |
| Audio bitrate | ۶۴ Kbps | |
| Stream type | Video, Video & Audio | |
| Dual-stream | Support | |
| Playback resolution | ۵MP/3MP/1080p/UXGA/720P/WD1/4CIF/VGA/DCIF/2CIF/CIF/QCIF | |
| Synchronous playback | ۱۶-ch | |
|
Record | Record/Capture mode | Manual recording/capture, Continuous recording/capture, Motion detection record/capture, Alarm record/capture, Motion | Alarm record/capture, Motion & Alarm record/capture |
| Playback mode | Instant playback, Normal playback, Event playback, Tag playback, Picture playback (not available for 7604HI-ST) | |
| Backup mode | Normal backup, Event backup, Picture backup (not available for 7604HI-ST) | |
| Network | Protocol | IPv6, HTTPS, UPnP™, SNMP, NTP, SADP, SMTP, NFS, iSCSI, PPPoE, etc. |
| Hard disk | Type | ۲ SATA interfaces |
| Capacity | Up to 4 TB capacity for each disk | |
|
External interface | Two-way audio | ۱-ch, RCA (2.0 Vp-p, 1 KΩ) (Using audio input) |
| Network interface | ۱ | |
| ۱۰M/100M/1000M self-adaptive Ethernet interface | ||
| Serial interface | ۱ RS-485 half-duplex interface | |
| USB port | ۲ ×USB2.0 | |
| Alarm in/out | Optional | |
|
General | Power supply | ۱۲ VDC |
| Consumption (without hard disk) | Max. 10W | |
| Working temperature | -۱۰ ºC ~ +55 ºC (14 ºF ~ 131 ºF) | |
| Working humidity | ۱۰%~۹۰% | |
| Chassis | ۱U chassis | |
| Dimensions (W ×D ×H) | ۴۴۵ ×۲۹۰ ×۴۵ mm (17.5 ×۱۱.۴ ×۱.۸ in) | |
| Weight | Approx. 2 kg / 4.4 lb (without hard disk) |
