دستگاه DVR مدل RS-964LFS3
مشخصات و ویژگی های دستگاه DVR مدل RS-964LFS3 به همراه قیمت و جزئیات این محصول در نظارت گستر ایمن > Up to 64 cameras with 1080p realtime live view
مشخصات
- تعداد هارد دیسک :
- 8
- تعداد کانال تصویر :
- 8
- تعداد کانال ورودی صدا :
- 16
- حداکثر ظرفیت هارد دیسک (هر عدد) :
- 32 ترابایت
- خروجی تصویر :
- HDMI، TV، VGA
- قابلیت انتقال تصویر از طریق اینترنت یا شبکه :
- بله
- کیفیت تصویر :
- CIF
- Bit Rate :
- ۴۸~۴۰۹۶Kb/s
- Alarm Input :
- ۱۶ channel
- Relay Output :
- ۶ channel
- Sync Playback :
- ۱/۴/۹/۱۶
- USB :
- ۴ ports (2 Rear)
توضیحات محصول
> Up to 64 cameras with 1080p realtime live view- > H.264 dual-stream video compression
- > All channel 2CIF or every 8 channel: 1ch D1 & 7ch CIF realtime recording
- > HDMI / VGA / TV / Spot simultaneous video output
- > 16 channel synchronous realtime playback, GRID interface & smart search
- > 3D intelligent positioning with Dahua PTZ camera
- > Support 8 SATA HDDs up to 32TB, 1eSATA up to 16TB, 4 USB2.0
- > Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
| Model | RS-964LFS3 | |
| System | ||
| Main Processor | Dual-core embedded processor | |
| Operating System | Embedded LINUX | |
| Video | ||
| Input | ۶۴ channel, BNC | |
| Standard | NTSC(525Line, 60f/s), PAL(625Line, 50f/s) | |
| Audio | ||
| Input | ۱۶ channel, BNC | |
| Output | ۱ channel, BNC | |
| Two-way Talk | ۱ channel Input, 1 channel Output, BNC | |
| Display | ||
| Interface | ۱ HDMI, 1 VGA, 1 TV, 1 Spot, BNC | |
| Resolution | ۱۹۲۰ ×۱۰۸۰, ۱۲۸۰ ×۱۰۲۴, ۱۲۸۰×۷۲۰, ۱۰۲۴×۷۶۸ | |
| Display Split | ۱/۴/۸/۹/۱۶/۲۵/۳۲/۶۴ | |
| Privacy Masking | ۴ rectangular zones (each camera) | |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording | |
| Recording | ||
| Video/Audio Compression | H.264 / G.711 | |
| Resolution | D1/4CIF(704×۵۷۶/۷۰۴×۴۸۰)/۲CIF(704×۲۸۸/۷۰۴×۲۴۰)/CIF(352×۲۸۸/۳۵۲×۲۴۰)/QCIF(176×۱۴۴/۱۷۶×۱۲۰) | |
| Record Rate | Main Stream | All channel 2CIF@25/30fps or every 8ch: 1ch D1 & 7ch CIF@25/30fps |
| Sub Stream | CIF/QCIF(1~25/30fps) | |
| Bit Rate | ۴۸~۴۰۹۶Kb/s | |
| Record Mode | Manual, Schedule(Regular(Continuous), MD, Alarm), Stop | |
| Record Interval | ۱~۱۲۰ min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec | |
| Video Detection & Alarm | ||
| Trigger Events | Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Spot, Buzzer & Screen tips | |
| Video Detection | Motion Detection, MD Zones: 396(22×۱۸), Video Loss & Camera Blank | |
| Alarm Input | ۱۶ channel | |
| Relay Output | ۶ channel | |
| Playback & Backup | ||
| Sync Playback | ۱/۴/۹/۱۶ | |
| Search Mode | Time/Date, Alarm, MD & Exact search (accurate to second), Smart search | |
| Playback Functions | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom | |
| Backup Mode | USB Device / eSATA Device / Internal SATA burner/ Network | |
| Network | ||
| Ethernet | RJ-45 port (10/100/1000M) | |
| Network Functions | HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, Alarm Server | |
| Max. User Access | ۲۰ users | |
| Smart Phone | iPhone, iPad, Android, Windows Phone | |
| Storage | ||
| Internal HDD | ۸ SATA ports (8HDDs or 6HDDs+1CD/DVD-RW), up to 32TB | |
| External HDD | ۱ eSATA port (Max 4 SATA HDDs), up to 16TB | |
| Auxiliary Interface | ||
| USB | ۴ ports (2 Rear), USB2.0 | |
| RS232 | ۱ port, For PC communication & Keyboard | |
| RS485 | ۱ port, For PTZ control | |
| General | ||
| Power Supply | AC100V~240V, 50/60Hz | |
| Power Consumption | ۴۵W (Without HDD) | |
| Working Environment | -۱۰°C ~+55°C / 10~90%RH / 86~106kpa | |
| Dimension(W×D×H) | ۳U, 439.7mm×۴۴۸mm×۱۳۳mm | |
| Weight | ۸KG (Without HDD) |
