دستگاه NVR مدل RS-2108PNVR
مشخصات و ویژگی های دستگاه NVR مدل RS-2108PNVR به همراه قیمت و جزئیات این محصول در نظارت گستر ایمن 8 CHANNEL 1U NETWORK VIDEO RECORDER
مشخصات
- تعداد کانال تصویر :
- 48، 8
- خروجی تصویر :
- HDMI، VGA
- مدل :
- RS-2108PNVR
- Power consumption :
- 12W
- Max user access :
- ۲۰ users
- Relay output :
- ۱
- Alarm input :
- ۲
توضیحات محصول
8 CHANNEL 1U NETWORK VIDEO RECORDER
Support up to 8 channel IP camera
Support UP 2 MP Resolution recording
Max 48 Mbps Bit rate input
Playback 8 CH sync real time
HDMI, VGA, CVBS output (1920*1080p)
Support 1 SATA, 2 USB 2/0
Support 2/1 Alarm I/O, 1/1 Two-way Talk
RJ45 (100) Mbps, 4PoE
Support Onvif Version 2.0 conformance
| Model | RS-2108PNVR |
| System | |
| Operating system | Embedded LINUX |
| Video | |
| IP video Input | ۸ channel |
| Audio | |
| Input | – |
| Output | – |
| Two-way talk | ۱ channel input, 1 channel output, RCA |
| Display | |
| Interface | ۱HDMI, 1 VGA |
| Resolution | ۱۹۲۰×۱۰۸۰, ۱۲۸۰×۱۰۲۴, ۱۲۸۰×۷۲۰, ۱۰۲۴×۷۶۸ |
| Display split | ۱/۴/۸/۹ |
| Privacy masking | – |
| Recording | |
| Video/ compression | H.264 / MJPEG |
| Resolution | ۱۰۸۰P(1920×۱۰۸۰) / ۷۲۰P(1280×۷۲۰) / D1(704×۵۷۶/۷۰۴×۴۸۰) & etc. |
| Record rate | Max 48Mbps (eg. 6ch 1080P@8Mbps & etc.) |
| Record interval | ۱~۱۲۰ min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Alarm& video detection | |
| Alarm input | ۲ |
| Relay output | ۱ |
| Trigger events | Recording, PTZ, Tour, Video Push, Email, FTP, Buzzer & Screen tips |
| Video detection | Motion Detection, MD Zones: 396(22×۱۸), Video Loss & Camera Blank |
| Playback & backup | |
| Sync playback | ۱/۴/۹ |
| Search mode | Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
| Backup mode | USB Device / Network |
| Playback function | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
| Network | |
| Ethernet | ۱RJ-45 port (10/100Mbps) |
| PoE | ۴ ports (IEEE802.3af) |
| Smart phone | iPhone, iPad, Android, Windows Phone |
| Network function | HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, IP Search(Support Raster IP camera, DVR, NVS and etc.) |
| Max user access | ۲۰ users |
| Storage | |
| Internal HDD | ۱ SATA port, up to 4TB |
| Auxiliary interface | |
| USB interface | ۲ ports (1 Rear), USB2.0 |
| RS-232 | – |
| RS-485 | – |
| General | |
| Power supply | NVR: DC12V/2A, PoE:DC48V/1.04A |
| Power consumption | NVR: 12W (without HDD), PoE: Max. 15W each |
| Working environment | ۰°C~+50°C/10%~90%RH/86~106kpa |
| Dimension | Mini 1U, 325mm×۲۴۰mmx45mm |
| Weight | ۱.۲۵kg (without HDD) |
