دستگاه DVR مدل RS-8204HFL2
مشخصات و ویژگی های دستگاه DVR مدل RS-8204HFL2 به همراه قیمت و جزئیات این محصول در نظارت گستر ایمن دستگاه DVR مدل RS-8204HFL2
مشخصات
- خروجی تصویر :
- HDMI، VGA
- مدل :
- RS-8204HFL2
- Analog video input :
- ۴-ch
- IP video input :
- ۱-ch
- Audio bit rate :
- ۶۴ Kbps
- Synchronous :
- ۴-ch
- USB interface :
- ۲, USB 2.0
- Power supply :
- ۱۲ VDC
- Working humidity :
- ۱۰% ~ ۹۰%
- Dimensions :
- ۳۱۵ × ۲۳۰ × ۴۵
توضیحات محصول
Connectable to the network cameras and network domes.
l Main stream supports up to WD1 resolution and sub stream supports CIF/QCIF resolution.
l Simultaneous HDMI/VGA and CVBS outputs.
l HDMI/VGA output at up to 1920×1080P resolution.
l Channel-zero encoding.
l Support dual stream.
l Video quality diagnostics.
l HDD quota management; different capacity can be assigned to different channel.
l Holiday recording schedule configuration.
l Smart searching for the event triggered record files.
l Smart playback for record files of the analog cameras.
l Digital zoom of video in live view or playback mode.
l Up to 16-ch synchronous playback.
l 1 self-adaptive 10M/100M /1000M network interface.
l IPv6 is supported.
l Network detection function.
l NTP, SMTP, NFS, UPnP™ and iSCSI protocols supported.
l Support alarm push notification (in live video or playback) on the linked mobile phones when alarm event occurs.
| Model | RS-8204HFL2 | |
| Video/Audio input | Video compression | H.264 |
| Analog video input | ۴-ch | |
| IP video input | ۱-ch | |
| Up to 720P resolution | ||
| Video input interface | BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive | |
| Audio compression | G.711u | |
| Audio input | ۱-ch, RCA (2.0 Vp-p, 1 kΩ) | |
| Two-way audio input | ۱-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input) | |
| Video/Audio output | HDMI/VGA output | ۱-ch, resolution: ۱۰۸۰P: 1920×۱۰۸۰/۶۰Hz, SXGA: 1280×۱۰۲۴/۶۰Hz, ۷۲۰P: 1280×۷۲۰/۶۰Hz, XGA: 1024×۷۶۸/۶۰Hz |
| CVBS output | ۱-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × ۵۷۶, NTSC: 704 × ۴۸۰ | |
| Encoding resolution | WD1 / 4CIF / 2CIF / CIF / QCIF | |
| Frame rate | ۲۵ fps (P) / 30 fps (N) | |
| Video bit rate | ۳۲ Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps) | |
| Audio output | ۱-ch, RCA (Linear, 1 kΩ) | |
| Audio bit rate | ۶۴ Kbps | |
| Dual-stream | Support; sub-stream @ CIF/ QCIF | |
| Stream type | Video, Video & Audio | |
| Synchronous playback | ۴-ch | |
| Hard disk | SATA | ۱ SATA interface |
| Capacity | Up to 4TB capacity for each disk | |
| External interface | Network interface | ۱, RJ45 10M / 100M Ethernet interface |
| Serial interface | ۱ RS-485 interface, half-duplex | |
| USB interface | ۲, USB 2.0 | |
| General | Power supply | ۱۲ VDC |
| Consumption (without hard disk or DVD-R/W) | ≤ ۱۰ W | |
| Working temperature | -۱۰ ºC ~+55 ºC | |
| Working humidity | ۱۰% ~ ۹۰% | |
| Chassis | Standalone 1U chassis | |
| Dimensions (W × D × H) | ۳۱۵ × ۲۳۰ × ۴۵ mm | |
| Weight (without hard disk or DVD-R/W) | ≤ ۲ kg |
