دوربین مدار بسته دام RS-SDI1318H

توضیحات محصول

Camera & Video

• > 1/3” 1.3Megapixel SONY Progressive Scan CCD
• > Powerful 18x optical zoom and 12x digital zoom
• > H.264 & Dual-stream video encoding and JPEG image capture
• > 12/15fps @1.3M(1280×960) & 25/30fps @720P resolution
• > Day/Night(ICR), Auto iris, Auto focus, AWB, BLC
• > Up to 24 privacy masking areas
• > Built-in Web server, NVR, CMS(PSS/DSS) & DMSS

Dome Drive

• > Max 240 °/s pan speed, 360° continuous pan rotation & auto flip with no blind spot monitor
• > Up to 255 preset, 5 auto scan, 8 tour, 5 pattern
• > Auto recognition of general protocols such as DH-SD, Pelco-P/D, and etc
• > Speed setup according to the focal distance, auto rotation speed adjust in accordance with the lens zoom rate
• > Auto restore to previous PTZ and lens status after power failure
• > Time Task: Auto activation of Preset/Scan/Tour/ Pattern by preset-time
• > Idle Motion: Call preset/tour and etc operations after idle for the specified time (including the idle status after the system boots up)
• > OSD and operation prompts of various languages
• > Build-in 7/2 channel alarm input/output
• > Intelligent 3D positioning function
• > IP66 all-environments protection, 4000V thunder-proof
• > Easy installation with user-friendly designs

IR LED

• > The longest distance of the build-in IR LED is over 100m

• لنز 4.5~81 میلیمتر
• کیفیت تصویر 1.3 مگاپیکسل
• مادون قرمز 100 متر
• برند Raster Red
• نوع دوربین اسپید دام
• Onvif ندارد
• POE ندارد
• ضبط صدا دارد
• Alarm دارد
•


  Model	RS-SDI1318H
  Camera
  Image Sensor	۱/۳” ۱.۳M Progressive Scan CCD
  Effective Pixels	۱۲۹۶(H) x 966(V)
  Lens	۱۸x optical zoom
  f=4.5mm(Wide)~81mm(Tele), F1.6~F2.7
  Digital Zoom	۱۲x
  Horizontal Viewing Angle	۵۱.۶°(Wide)~3.1°(Tele)
  Min. Object Distance	۱۰mm(wide) ~ 1000mm(Tele)
  Min. Illumination	۰.۱Lux/F1.6(Color), 0.01Lux/F1.6(B/W), 0Lux (IR ON)
  Electronic Shutter	NTSC:1/4~1/10000s, PAL:1/3~1/10000s, 20level
  White Balance	Auto/ATW/Indoor/Outdoor/Manual
  BLC	ON/OFF
  WDR	/
  Day/Night	Auto(ICR) / Color / B/W
  S/N Ratio	More than 50 dB
  Privacy Masking	ON/OFF (up to 24 privacy masking areas)
  Analog Video Output	BNC(1.0Vp-p / 75Ω), PAL / NTSC
  Video & Audio
  Video Compression	H.264 / MPEG4
  Image Resolution	۱.۳M(1280×۹۶۰) / ۷۲۰P(1280×۷۲۰) / D1(704×۵۷۶/۷۰۴×۴۸۰) / CIF(352×۲۸۸/۳۵۲×۲۴۰) / QCIF(176×۱۴۴/۱۷۶×۱۲۸)
  Encoding Speed	Main Stream	PAL: 1.3M(1~12fps), 720P(1~25fps) / NTSC: 1.3M(1~15fps), 720P(1~30fps)
  Extra Stream	PAL: D1/CIF/QCIF (1~25fps) / NTSC: D1/CIF/QCIF (1~30fps)
  Bit Rate	۳۲K~8Mbps
  Audio Compression	G.711a(32Kbps) / AMR(10.2Kbps)
  Audio Mode	Off/Audio input/Audio output
  Dome Drive
  Pan/Tilt Range	Horizontal: 0°~۳۶۰° endless, Vertical: -2°~۹۰° auto flip 180° to continue monitor
  Manual Control Speed	Horizontal: 0.1° ~۱۶۰° /s, Vertical: 0.1° ~۱۲۰° /s
  Preset Speed	Horizontal: 240° /s, Vertical: 200° /s
  Preset	۲۵۵
  PTZ Mode	۵ Auto Pattern, 8 Auto Tour, 5 auto scan
  ۳D Positioning	Yes
  Speed Setup	Human-oriented focal Length/ speed adaptation
  Info Display	Time, Location, Dome title, Dome coordinates, Temperature, Alarm, and etc.
  Power up Action	Auto restore to previous PTZ and lens status after power failure
  Idle Motion	Activate preset/scan/tour/ patter if there is no command in the specified period.
  Time Task	Auto activation of Preset/Scan/Tour/ Pattern by preset-time
  Alarm	۷/۲ alarm input/output, Triggering Preset/Tour/Pattern/Scan/Alarm output
  Protocol	DH-SD, Pelco-P/D, Auto recognition of general protocols
  IR LED	Auto / Near light / Far light / OFF, 6 Near light + 8 Far light, up to 100m
  Network
  Ethernet	RJ-45 (10/100Base-T)
  Network Functions	HTTP, TCP/IP, ICMP, RTSP, RTP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server
  Max Remote Users	۲۰ Users simultaneously
  Processor	TI DaVinci Series DSP
  Operating System	Embedded LINUX
  Resource	Simultaneous remote monitoring, remote operation & local recording
  Remote Operation	Monitor, PTZ control, Voice Intercom, System setting, Playback, File download, Log information, Maintenance & Upgrade
  Local Recording	SD/SDHC, Max 32GB
  User Interface	WEB, CMS(DSS/ PSS), DMSS, NVR
  General
  Power Supply	AC 24V/3A (±۱۰%)
  Power Consumption	۱۲W/30W(IR LED ON)
  Working Temperature	-۲۰ºC ~ 60ºC
  Working Humidity	<90%
  Protection Level	IP66, 4000V thunder, surge and wave protection
  Dimension	Φ۲۳۰(mm) x 352(mm)
  Weight	۷.۰kg
