دوربین مدار بسته دام RS-IP4100HD
مشخصات و ویژگی های دوربین مدار بسته دام RS-IP4100HD به همراه قیمت و جزئیات این محصول در نظارت گستر ایمن دسته: دوربین دام تحت شبکه.
مشخصات
- لنز :
- 4 میلیمتر
- کیفیت تصویر :
- 1.3 مگاپیکسل
- مادون قرمز :
- 10 متر
- برند :
- Raster Blue
- نوع دوربین :
- دام
- Onvif :
- دارد
- POE :
- POE
- ضبط صدا :
- ندارد
- Alarm :
- دارد
توضیحات محصول
- Up to 1.3 megapixel (1280 × 960 @ 30 fps) resolution
- Standard video compression with high compression ratio
- Progressive scan CMOS
- Small and nice
- PoE (Power over Ethernet)
- Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB
- IR range approx. 10 meters (-I)
- Two-way audio
- Built-in microphone and speaker(-S)
- Support Wi-Fi(-W)
- IR cut filter with auto switch
- 3D digital Noise Reduction
- Support dual stream, and the sub-stream for mobile surveillance
- Support Backlight Compensation, Digital Wide Dynamic Range, Auto-electronic shutter and so on
- Three-axis adjustment for easy installation
- IP66
- Other functions: heartbeat, mirror image, reset button, etc.
- لنز 4 میلیمتر
- کیفیت تصویر 1.3 مگاپیکسل
- مادون قرمز 10 متر
- برند Raster Blue
- نوع دوربین دام
- Onvif دارد
- POE دارد
- ضبط صدا ندارد
- Alarm دارد
| Model | RS-IP4100HD |
| parameters | ۱.۳ megapixel CMOS Network Mini Dome Camera |
| Camera | |
| Image Sensor | ۱/۳″ Progressive Scan CMOS |
| Min. Illumination | ۰.۰۱Lux @(F1.2,AGC ON) ,0 Lux with IR |
| Shutter Speed | ۱/۲۵ s to 1/100,000 s |
| Lens | ۴mm@F2.0 (2.8mm,6mm optional) Angle of view: 68°(۴mm) |
| Lens Mount | M12 |
| Day &Night | -I: IR cut filter with auto switch |
| Digital Noise Reduction | ۳D Digital Noise Reduction |
| Angle of adjustment | Pan: -30°-۳۰°, Tilt: 0~75°, Rotation: 0-360° |
| WDR | Digital WDR |
| Compression Standard | |
| Video Compression | H.264 / MJPEG |
| H.264 encoding level | Main Profile |
| Video Bit Rate | ۳۲Kbps~16Mbps |
| Audio Compression | G.711/G.726 |
| Audio Bit Rate | ۶۴Kbps(G.711) / 16Kbps(G.726) |
| Image | |
| Max. Resolution | ۱۲۸۰ × ۹۶۰ |
| Frame Rate | ۵۰Hz: 25fps (1280 × ۹۶۰), ۲۵fps (1280 × ۷۲۰) ۶۰Hz: 30fps (1280 × ۹۶۰), ۳۰fps (1280 × ۷۲۰) |
| Image Settings | Saturation, Brightness, Contrast, Acutance adjustable by client software or web |
| Backlight compensation | Yes, zone optional |
| Network | |
| Network Storage | Local storage: Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB. NAS |
| Alarm Trigger | Motion detection, Dynamic Analysis, Tampering alarm, Network disconnect, IP address conflict, Storage full, storage error |
| Protocols | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour(SIP optional) |
| Interface protocol | ONVIF,PSIA,CGI |
| General function | Flash-prevention, dual stream, heartbeat, mirror, password protection, video cover, watermark |
| Interface | |
| Communication | ۱ RJ45 10M/100M Ethernet interface |
| Alarm interface | -S: 1 alarm input and 1 alarm output |
| Wi-Fi Specification(Only for the products with Wi-Fi module built-in) | |
| Wireless Standards | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | ۲.۴ GHz ~ 2.4835 GHz |
| Channel Bandwidth | ۲۰/۴۰MHz |
| Security | ۶۴/۱۲۸-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transfer Rates | ۱۱b: 11Mbps ۱۱g: 54Mbps ۱۱n: up to 150Mbps |
| Wireless Range | Outdoor: 200m，Indoor: 50m(depend on environment) |
| General | |
| Operating Conditions | -۳۰ °C – ۶۰ °C Humidity 95% or less (non-condensing) |
| Power Supply | DC12V±۱۰% / PoE |
| Power Consumption | ۵W MAX |
| IR Range | -I: 10 meters |
| Protect level | IP66 |
| Dimensions (mm) | ۹۹.۹×۹۷.۵×۵۶.۵ |
| Weight | ۳۵۰g |
