دوربین مدار بسته دام RS-SDI17036XI
مشخصات و ویژگی های دوربین مدار بسته دام RS-SDI17036XI به همراه قیمت و جزئیات این محصول در نظارت گستر ایمن دسته: دوربین اسپید دام آنالوگ.
مشخصات
- OSD :
- بله
- دید در شب :
- بله
- ضد آب :
- IP66
- لنز :
- 3.3~119 میلیمتر میلیمتر
- مدل :
- RS-SDI17036XI
- نوع دوربین :
- دام
- کیفیت :
- 700
- نوع دوربین :
- اسپید دام
- digital zoom :
- 16x
- Optical Zoom :
- 36x
توضیحات محصول
1/3” SONY Interline Xview HAD-II CCD- 750TVL Horizontal resolution
- 36x Optical Zoom,16x digital zoom
- Up to 100 M IR distance
- True Day/Night,3D DNR,DWDR
- 3D Intelligent positioning
- Alarminput & output
- 24VAC,IP66
- کیفیت تصویر 700TVL
- مادون قرمز 100 متر
- منو OSD دارد
- سنسور CCD SONY
- برند Raster Blue
- لنز 3.3~119 میلیمتر
- نوع دوربین اسپید دام
| Model Parameter | RS-SDI17036XI
| |
| Series High Speed Dome | ||
| Camera | Image Sensor | ۱/۴″ Sony CCD |
| Effective Pixel | PAL: 976(H)×۵۸۲(V) | |
| Horizontal Resolution | Color: 700 TVL B/W: 750 TVL | |
| Signal System | PAL/NTSC | |
| Min. Illumination | ۰.۰۲Lux/(F1.6, AGC ON), 0.0008Lux /(F1.6, AGC ON, sensitivity×۲۵۶) (color) ۰.۰۰۲Lux/(F1.6, AGC ON), 0.00008Lux /(F1.6, AGC ON, sensitivity×۲۵۶)(B/W) ۰ Lux with IR | |
| White Balance | Auto / One touch WB/ ATW / Indoor / Outdoor | |
| AGC | Auto / Manual | |
| S / N Ratio | ≥ ۵۰dB | |
| DNR | High/Medium/Low/off | |
| WDR | ۱۲۸x(On/Off/Auto) | |
| Shutter Time | PAL: 1-1/10,000s NTSC: 1-1/10,000s | |
| Day & Night | IR Cut Filter | |
| Digital Zoom | ۱۶x | |
| Privacy Mask | ۸ privacy masks programmable; a maximum of 8 zones can be masked simultaneously on the same video screen | |
| Focus Model | Auto / Semiautomatic / Manual | |
| Lens | Focal Length | ۳.۳-۱۱۹mm, 36X |
| Zoom Speed | Approx.6 s(Optical Wide-Tele) | |
| Angle of View | ۵۷.۱-۱.۷ degree(Wide-Tele) | |
| Min. Working Distance | ۱۰-۱۰۰۰mm (Wide-Tele) | |
| Aperture Range | F1.4-F3.7 | |
| Pan and Tilt | Pan Range | ۳۶۰°endless |
| Pan Speed | Pan Manual Speed: 0.1°-۱۶۰°/s, Pan Preset Speed: 240°/s | |
| Tilt Range | -۱۵°-۹۰° (Auto Flip ) | |
| Tilt Speed | Tilt Manual Speed: 0.1°-۱۲۰°/s, Tilt Preset Speed: 200°/s | |
| Proportional Zoom | Rotation speed can be adjusted automatically according to zoom multiples | |
| Number of Preset | ۲۵۶ | |
| Patrol | ۸ patrols, up to 32 presets per patrol | |
| Pattern | ۴ patterns, with the total recording time not less than 10 minutes | |
| Power-off Memory | Support | |
| Park Action | Preset / Patrol / Pattern / Pan / Tilt / Auto / Random / Frame / Panorama scan | |
| PTZ Position Display | On / Off | |
| Compass | Support , the north can be set | |
| Scheduled Task | Preset / Patrol / Pattern / Pan / Tilt / Auto / Random / Frame / Panorama scan | |
| Infrared | IR Range | ۱۰۰m |
| IR irradiation angle | Automatically adjusted, depending on the zoom ratio | |
| Input/ Output | Monitor Output | ۱.۰V[p-p] / 75Ω, PAL or NTSC composite, BNC |
| General | Menu Language | English/Chinese |
| RS-485 Protocols | , Pelco-P, Pelco-D, self-adaptive | |
| Power | ۲۴ VAC(-A model); 12 VDC(-D model) Max.30W(IR LED On, Heater On) Max.24W(IR LED On) Max.15W(IR LED Off, Heater Off) | |
| Working Temperature / Humidity | -۳۰ ℃-۶۵℃(-۲۲℉-۱۴۹℉)(outdoor dome) ۹۰% or less | |
| Protection Level | IP66 standard (outdoor dome) TVS 4,000V lightning protection, surge protection and voltage transient protection | |
| Mounting | Various mounting modes optional | |
| Dimensions | Φ۲۴۵ ×۳۹۹mm (Φ۹.۶۵” ×۱۵.۷۱” ) (Outdoor) | |
| Weight (approx.) | ۵.۵kg(12.13Ibs) |
