ویبراتور های توربینی EURO VIBRA مدل‌های VT

توضیحات محصول

​

• Anodized stainless aluminum body
• Version ATEX Ex II 2G c T6 Certification ASEV SEV 04 ATEX 010
• Compressed air operating range from 2 to 6 bar
• Removable, watertight steel flanges
• Special-profile turbine mounted on HF bearings
• Reduced air consumption
• Non-lubricated dry air operation
• Supplied with intake manifold and silencer, boltless

The VT turbine vibrator consists of an aluminum turbine with integrated lead weights. The turbine’s special blade-shaped profile generates high frequencies and large amplitudes of vibration. As the frequency can be infinitely varied by means of pressure regulation, the VT turbine vibrator offers a broad vibration spectrum, making it suitable for a wide range of applications. High-quality grooved ball bearings are lubricated for life and require no maintenance.

The VT turbine vibrator works in any mounting position. At around 70 dBA, it is one of the quietest pneumatic vibrators on the market. Dry, clean, oil-free compressed air is required for long, trouble-free operation.

The VT turbine vibrator can be coupled with aVTC quick-attach systemor with a hopper vibrator support. It can be installed on hoppers, containers and small silos for emptying or wall cleaning. The VT turbine vibrator is also available in a high-temperature version, so don’t hesitate to ask us.
